| Camera | |
| Image Sensor: | 2.0 megapixel progressive scan CMOS |
| Signal System: | PAL/NTSC |
| Effective Pixels: | 1920 (H) × 1080 (V) |
| Min. Illumination: | Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s |
| Lens: | 2.7 mm to 13.5 mm motorized vari-focal lens |
| Lens Mount: | φ14 |
| Adjustment Range: | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| Day& Night: | IR cut filter |
| Video Frame Rate: | PAL: 1080p@25fps |
| | NTSC: 1080p@30fps |
| Synchronization: | Internal Synchronization |
Menu | |
| 3D DNR (Digital Noise Reduction): | Level 1 to 9 |
| D/N Mode: | Auto/Color/BW (Black and White) |
| BLC: | Support |
| AGC: | High/Medium/Low |
| WDR: | Yes |
| Language: | English |
| Function: | Brightness, Sharpness, 3D DNR, Mirror, Smart IR |
Interface | |
| Video Out: | 1 HD analog output |
General | |
| Operating Conditions: | -40 °C - 60 °C (-40 °F - 140 °F) |
| | Humidity 90% or less (non-condensing) |
| Power Supply: | 12 VDC ±25%;-A: 24 VAC ±15%, 12 VDC ±20%*You are recommended to use one power adapter to supply the power for one camera |
| Power Consumption: | Max. 7.7 W;-A: Max. 9.7 W |
| Weather Proof: | IP67 |
| IR Range: | Up to 70 m |
| Dimension: | 84.5 mm × 92 mm × 255.1 mm (3.33" × 3.62" × 10") |
| Weight: | Approx. 648 g (1.43 lb.) |
| | -A: Approx. 695 g (1.53 lb.) |
